a：安裝準備

A: setup ready

a.1 板式橡膠支座安裝處宜設置支承墊石,支承墊石平面尺寸大小應按局部承壓計算確定,墊石長度、寬度應比支座相應的尺寸至少增加50mm左右，其高度應為100mm以上，且應考慮便于支座更換頂梁時千斤頂?shù)陌惭b位置。

A.1 rubber bearing installation should set the bearing pad stone, bearing pad stone plane size should be according to the local pressure calculation, cushion stone length and width should be higher than the corresponding support size increase of at least about 50mm, its height should be more than 100mm, and should be considered for replacement when the top beam jack installation position.

a.2 支座墊石內應布置鋼筋網，鋼筋直徑為8mm時，間距宜為50mm×50mm，橋梁墩、臺內應有豎向鋼筋延伸至支座墊石內，支座墊石的混凝土強度等級不應低于C30。

A.2 bearing pad stone internal layout of steel mesh, bar diameter is 8mm, the suitable spacing is 50mm * 50mm, bridge pier and abutment should have vertical bars extending to the bearing pad stone, concrete strength bearing pad stone should not be less than C30.

a.3 支座墊石表面應平整、清潔、干爽、無浮沙。支座墊石頂面標高要求準確無誤。在平坡情況下，同一片梁兩端支承墊石及同一橋墩、臺上支承墊石應處于同一設計標高平面內，其相對高差不應超過±1.5 mm，同一支承墊石高差應小于0.5 mm。

A.3 bearing pad stone surface should be smooth, clean, dry, no sand. The elevation of the top of the cushion stone should be accurate and correct. In the case of flat slope, with a beam at both ends of bearing pad stone piers, and the same table bearing pad stone should be in the same plane design elevation, the relative height should not exceed 1.5 mm, with a height of bearing pad stone should be less than 0.5 mm.

阜陽150*150*35矩形板式橡膠支座價格  131 6657 0832

b： 支座安裝

B: support installation

b.1 支座進場后，應檢查支座上是否有制造商的商標或永久性標記。安裝時，應按照設計圖紙要求，在支承墊石和支座上均標出支座位置中心線，以保證支座準確就位。

When the B.1 support comes into play, check that the manufacturer has a trademark or permanent tag on the mount. When installing, the center line of the bearing shall be marked on the supports, stones and supports according to the requirements of the design drawings to ensure that the bearings are in exact position.

b.2 支座安裝時，應防止支座出現偏壓或產生過大的初始剪切變形。安裝完成后，必須保證支座與上、下部結構緊密接觸，不得出現脫空現象。對未形成整體的梁板結構，應避免重型車輛通過。

When the B.2 support is installed, the abutment shall be prevented from biasing or producing excessive initial shear deformation. After completion of installation, it is necessary to make sure that the supports are in close contact with the upper and lower structures and shall not be void. For heavy beam slab structures, heavy duty vehicles should be avoided.

b. 3 橋梁墩臺的設計應考慮支座養護、更換的需要。任何情況下，不允許兩個或兩個以上的支座沿梁縱向中心線在同一支承點并排安裝；在同一根梁（板）上，橫向不宜設置多于兩個支座；不同規格的支座不應并排安裝。

The design of B. 3 bridge pier should consider the need to support maintenance and replacement. In any case, does not allow two or more than two bearings along the beam longitudinal center line on the same support mounted side by side on the same; beam (plate), transverse should not be set more than two bearings; bearing different specifications should not be installed side by side.

阜陽150*150*35矩形板式橡膠支座價格  131 6657 0832

b. 4 支座安裝后，應全面檢查是否有支座漏放，支座安裝方向、位置（與預埋鋼板的接觸、支座中心線位置）、支座規格型號是否有錯，臨時固定設施是否拆除，四氟滑板支座是否注入硅脂油（嚴禁使用潤滑油代替硅脂油）等現象，一經發現，應及時調整和處理，確保支座安裝后的正常工作，并記錄支座安裝后出現的各項偏差及異常情況。

B. 4 supports after installation, should check whether the support drain, installation direction and position of the support (contact and support center line position and pre buried steel), bearing specifications is wrong, whether the removal of temporary fixed facilities, PTFE sliding bearings are injected into the silicone oil (lubricating oil instead of silicone oil is prohibited to use). The phenomenon, once discovered, should be timely adjustment and treatment, ensure the normal work of bearing after installation, and record the deviation and abnormal situation after the installation of bearings.

b.5 支座使用階段平均壓應力σc=10MPa。支座橡膠彈性體體積Eb=2000MPa。

B.5 bearing stage, average compressive stress, sigma c=10MPa. Rubber elastomer volume Eb=2000MPa.

支座與混凝土接觸時，摩擦系數μ=0.3；與鋼板接觸時，摩擦系數μ=0.2；聚四氟乙xi板與不銹鋼板接觸（加硅脂時）摩擦系數μf=0.06,當溫度低于-25℃時，μf值增大30%，當不加硅脂時，μf值應加倍。

Bearing contact with concrete, friction coefficient of =0.3; and the steel plate contact, friction coefficient =0.2; PTFE plate contact with stainless steel plate (add grease when) the friction coefficient f=0.06, when the temperature is lower than -25 DEG C, F value increased 30%, when not add grease, F value should be doubled.

b.6 矩形支座安裝時以短邊尺寸順橋向放置。

The B.6 rectangular support is placed along the bridge with short side dimensions.

阜陽150*150*35矩形板式橡膠支座價格  131 6657 0832

施工注意事項：保持墩臺墊石頂面清潔。如果支承墊石標高差距超過標準要求，必須用水泥砂漿進行標高調整。在支承墊石上按設計圖標出中心，安裝時橡膠支座的中心與支承墊石中心線要吻合，以確保支座就位準確。在澆注梁體前，在支座上放置一塊比支座平面稍大的支承鋼 板，鋼板上焊接錨固鋼筋與梁體連接，并把支承鋼板視作澆梁模板的 一部分進行澆注，按以上方法進行，可以使支座與梁底鋼板及墊石頂面全部密貼。預制梁橡膠支座的安裝：安裝好預制梁橡膠支座的關鍵在于保證梁底在墊石頂面的平行、平整，使其和支座上、下表面全部密貼，不得出現偏壓、脫空和不均勻支承受力現象。施工程序如下：處理好支撐墊石，使支撐墊石標高一致。預制梁與支座接觸的底面要保持水平和平整。當有蜂窩漿和傾斜度時，要預先用水泥砂漿搗實、整平。

Note: keep the construction of pier pad stone tops clean. If the gap between supports and stones exceeds the standard requirements, the cement mortar shall be used for elevation adjustment. On the support pad stone, the center shall be designed according to the design icon, and the center of the rubber bearing shall be in conformity with the center line of the support pad when installing, so as to ensure that the bearing is in correct position. In the pouring of beam before placing a slightly larger than the bearing plane of the bearing plate on the support plate, welded anchor bar and beam body connection, and part of the supporting steel plate girder as a template for casting, according to the above method, can make the bearing beam and the bottom steel plate and pad stone tops all. Stick. Prefabricated bridge rubber bearing installation: key pre installed bridge rubber bearing pad stone is to ensure that the top surface of the beam bottom in parallel and smooth, and the support of the upper and lower surfaces all close, there shall be no bias, void and uneven supporting force. Construction procedures are as follows: handle support stone, so that the support pad stone elevation. The bottom surface of the precast beam and the support shall be kept level and smooth. When there is a slurry and tilt, it should be pre - compacted with cement mortar, leveling.

橡膠支座的正確就位先使支座和支承墊石按設計要求準確就位。架梁落梁時，T型梁的縱軸線要與支座中心線重合；板梁、箱梁的縱軸線與支座中心線相平行。為落梁準確，在架第一跨板梁或箱梁時，可在梁底劃好二個支座的十字位置中心，在梁的端立面上標出兩個支座的位置中心線的鉛直線，落梁時使之與墩臺上的位置中心線相重合。以后數跨可依照第一跨梁為基準進行。在架梁落梁時要平穩，防止壓偏或產生初始剪切變形,大家可以參考鐵路橋梁板式橡膠支座規格表 。在安裝 T型橋梁時，若橡膠支座比梁筋底寬，則應在支座與梁筋底之間加設比支座大的鋼筋混凝土墊塊或厚鋼板做過渡層，以免支座局 部受壓，而形成應力集中。鋼筋砼墊塊或厚鋼板要用環氧樹脂砂漿和梁筋底貼合粘結。落梁后，一般情況下橡膠支座頂面與梁面保持水平。預應力簡支梁，其支座頂面可稍后傾；非預應力梁其支座頂面可略微前傾，但傾斜角度不得超過5"。

The correct position of the rubber bearing first makes the bearing and the supporting stone accurately positioned according to the design requirements. When the frame beam falls, the longitudinal axis of the T beam should coincide with the central line of the bearing; the longitudinal axis of the plate beam and the box girder are parallel to the center line of the support. For the first frame in the fall beam accurately, cross slab beam or box girder, cross the center position can be marked two supports at the end of the beam, the lead line and mark the position the center line of two bearings in the end elevation on the beam, beam falling when the phase coincides with the position of the center line on the pier. The subsequent spans may be carried out on the basis of the first cross beam. When the frame beam is falling, it is necessary to be stable, to prevent partial deflection or initial shear deformation. The installation of T type bridge, if the rubber bearing ratio of beam bar bottom width should be in between the bearing and the bottom beam reinforcement added support than reinforced concrete pad or thick plate transition layer, to support local compression, and the formation of stress concentration. Reinforced concrete block or thick steel plate should be bonded with epoxy resin mortar and beam reinforcement. After falling beam, generally, the top surface of rubber bearing is kept level with the beam. Prestressed simply supported beam, its bearing top surface may later incline; non - prestressed beam, its bearing top surface may slightly forward, but the angle of inclination may not exceed 5".

維護

Maintain

1 )、 板式橡膠支座應定期進行養護和維修檢查，一旦發現問題，應及時進行修補或更換。

1) plate rubber bearings should be regularly maintenance and maintenance checks, once found problems, should be repaired or replaced in a timely manner.

2)、 板式橡膠支座及四氟滑板橡膠支座應檢查如下內容：

2) sheet rubber bearings and PTFE slide rubber bearings should be inspected as follows:

a： 支座是否出現滑移及脫空現象；

A: does the support appear slippage or disengaging?;

b： 支座的剪切位移是否過大（剪切角應不大于35°）；

B: is the shear displacement of the support too large (shear angle shall be no more than 35 degrees)?;

c： 支座是否產生過大的壓縮變形；（最大壓縮變形量不得超過0.07te

C: does the support produce excessive compression deformation (maximum compressive deformation shall not exceed 0.07te
